Drawing
22309 EK
Specifications
| Principal dimensions (d) | 45 |
| Principal dimensions (D) | 85 |
| Principal dimensions (B) | 23 |
| Basic load ratings dynamic (C) | 90 |
| Basic load ratings static (C0) | 88 |
| Fatigue load limit (Pu) | 9.5 |
| Speed ratings Lubrication grease | 5300 |
| Speed ratings Lubrication oil | 6700 |
| Mass | 0.6 |
| Dimensions (d) | 45 |
| Dimensions (d2) | 54.9 |
| Dimensions (D1) | 73.6 |
| Dimensions (b) | 5.5 |
| Dimensions (k) | 3 |
| Dimensions (r mim) | 1.1 |
| Abutment and filet dimensions (da min) | 52 |
| Abutment and filet dimensions (Da max) | 78 |
| Abutment and filet dimensions (ra max) | 1 |
| Calculation factors (e) | 0.26 |
| Calculation factors (Y1) | 2.6 |
| Calculation factors (Y2) | 3.9 |
| Calculation factors (Y0) | 2.5 |
