Product
Drawing
22328 CC/W33
Specifications
| Principal dimensions (d) | 140 |
| Principal dimensions (D) | 300 |
| Principal dimensions (B) | 102 |
| Basic load ratings dynamic (C) | 1290 |
| Basic load ratings static (C0) | 1560 |
| Fatigue load limit (Pu) | 132 |
| Speed ratings Lubrication grease | 1100 |
| Speed ratings Lubrication oil | 1500 |
| Mass | 36.5 |
| Dimensions (d) | 140 |
| Dimensions (d2) | 175 |
| Dimensions (D1) | 247 |
| Dimensions (b) | 16.7 |
| Dimensions (k) | 9 |
| Dimensions (r mim) | 4 |
| Abutment and filet dimensions (da min) | 157 |
| Abutment and filet dimensions (Da max) | 283 |
| Abutment and filet dimensions (ra max) | 3 |
| Calculation factors (e) | 0.35 |
| Calculation factors (Y1) | 1.9 |
| Calculation factors (Y2) | 2.9 |
| Calculation factors (Y0) | 1.8 |
