Drawing
23064 CCK/W33
Specifications
| Principal dimensions (d) | 320 |
| Principal dimensions (D) | 480 |
| Principal dimensions (B) | 121 |
| Basic load ratings dynamic (C) | 2240 |
| Basic load ratings static (C0) | 3800 |
| Fatigue load limit (Pu) | 285 |
| Speed ratings Lubrication grease | 800 |
| Speed ratings Lubrication oil | 1000 |
| Mass | 78 |
| Dimensions (d) | 320 |
| Dimensions (d2) | 360 |
| Dimensions (D1) | 433 |
| Dimensions (b) | 16.7 |
| Dimensions (k) | 9 |
| Dimensions (r mim) | 4 |
| Abutment and filet dimensions (da min) | 335 |
| Abutment and filet dimensions (Da max) | 465 |
| Abutment and filet dimensions (ra max) | 3 |
| Calculation factors (e) | 0.23 |
| Calculation factors (Y1) | 2.9 |
| Calculation factors (Y2) | 4.4 |
| Calculation factors (Y0) | 2.8 |
