Product
Drawing
24026 CCK30/W33
Specifications
| Principal dimensions (d) | 24026 |
| Principal dimensions (D) | 200 |
| Principal dimensions (B) | 69 |
| Basic load ratings dynamic (C) | 540 |
| Basic load ratings static (C0) | 815 |
| Fatigue load limit (Pu) | 81.5 |
| Speed ratings Lubrication grease | 1500 |
| Speed ratings Lubrication oil | 1900 |
| Mass | 8.05 |
| Dimensions (d) | 130 |
| Dimensions (d2) | 145 |
| Dimensions (D1) | 175 |
| Dimensions (b) | 5.5 |
| Dimensions (k) | 3 |
| Dimensions (r mim) | 2 |
| Abutment and filet dimensions (da min) | 140 |
| Abutment and filet dimensions (Da max) | 190 |
| Abutment and filet dimensions (ra max) | 2 |
| Calculation factors (e) | 0.31 |
| Calculation factors (Y1) | 2.2 |
| Calculation factors (Y2) | 3.3 |
| Calculation factors (Y0) | 2.2 |
