Product
Drawing
21311-E1-XL
Specifications
Principal dimensions (d) | 55 mm |
Principal dimensions (D) | 120 mm |
Principal dimensions (B) | 29 mm |
Basic load ratings dynamic (Cr) | request by email |
Basic load ratings static (Cor) | request by email |
Fatigue load limit (Pu) | 20200 N |
Speed ratings Lubrication grease | request by email |
Speed ratings Lubrication oil | request by email |
Mass | 1.19 kg |
Dimensions (d) | request by email |
Dimensions (d2) | request by email |
Dimensions (D1) | request by email |
Dimensions (b) | request by email |
Dimensions (k) | request by email |
Dimensions (r min) | 2 mm |
Abutment and filet dimensions (da min) | 66 mm |
Abutment and filet dimensions (Da max) | 109 mm |
Abutment and filet dimensions (ra max) | 2 mm |
Calculation factors (e) | 0.24 mm |
Calculation factors (Y1) | 2.84 mm |
Calculation factors (Y2) | 4.23 mm |
Calculation factors (Y0) | 2.78 mm |
